Plastic tanks
Custom vertical HDPE/PPH tanks for water, chemicals, fuel, food liquids and industrial use.
Overview
Plastopex manufactures plastic tanks for the efficient storage and handling of various types of liquids, chemicals and industrial media. The tanks are made of HDPE and PPH materials using spiral winding technology, in accordance with the required volume, the type of medium, the method of installation and the technical requirements of the project.
Plastic vertical tanks are used for drinking water, firefighting water, irrigation, technical water, wastewater, chemicals, fruit fermentation, alcoholic and non-alcoholic beverages, foodstuffs, petroleum, diesel fuel and heating oil. Due to their wide application they are suitable for households, schools, kindergartens, weekend settlements, hotels, agriculture, the food industry, chemical production and various technical systems.
HDPE and PPH materials provide high resistance to corrosion, moisture, chemical influences and wear. Smooth interior walls facilitate emptying, cleaning and maintenance, while the lower weight compared to traditional materials simplifies transport, handling and assembly. The tanks can be used as above-ground or, when the construction is designed for it, as buried systems according to the project and the conditions of the location.
Plastopex also manufactures tanks for special purposes, including thermally insulated tanks, double-walled tanks and tanks with additional equipment at the customer’s request. Thermally insulated tanks use polyurethane insulation between the walls in order to slow the exchange of heat between the medium and the environment. Double-walled tanks are used when an additional safety layer is needed, especially for more demanding industrial and chemical media.
The tanks can be equipped with various plastic fittings and accessories, such as connections with an internal thread, flanges, valves, taps, level indicators, inspection openings, vents, overflows, steps, anchoring, nozzles, holders for mixers and other equipment. The exact configuration is determined according to the purpose, volume, medium, space for assembly and manner of use.
Volumes from 250 l to 50,000 l are available, with the possibility of adapting the diameter, height, connections, openings, color and additional equipment. If you need a plastic tank for water, chemicals, fuel, food liquids or industrial use, the Plastopex team can help in selecting the appropriate solution and preparing a custom quote.
Applications
- Tanks for drinking, technical and firefighting water
- Tanks for irrigation and agricultural use
- Tanks for wastewater and sewage
- Tanks for chemicals and aggressive fluids
- Tanks for petroleum, diesel fuel and heating oil
- Tanks for fruit fermentation, alcoholic and non-alcoholic beverages
- Tanks for foodstuffs and the food industry
- Thermally insulated tanks and double-walled tanks for special purposes
- Industrial tanks with connections, fittings and equipment on request
Key Benefits
- Custom-made according to volume, dimensions, medium and method of installation
- HDPE and PPH materials resistant to corrosion, moisture and chemical influences
- Smooth interior walls for easier cleaning, emptying and maintenance
- Possibility of an above-ground or design-defined buried version
- Possibility of thermal insulation, a double wall and additional safety configuration
- Good mechanical resistance, static load capacity and pressure resistance
- Lower weight compared to traditional tanks, which facilitates transport and handling
- Do not require anti-corrosion protection like metal tanks
- Possibility of installing connections, valves, taps, level indicators and other equipment
- Suitable for a wide range of household, agricultural, food and industrial applications
Specifications
| Material | HDPE and PPH |
|---|---|
| Production technology | Spiral winding |
| Tank type | Vertical plastic tank |
| Volume | 250 l · 500 l · 1000 l · 1500 l · 2000 l · 2500 l · 3000 l · 4000 l · 5000 l · 6000 l · 7000 l · 8000 l · 10000 l · 12000 l · 15000 l · 20000 l · 25000 l · 30000 l · 35000 l · 40000 l · 50000 l |
| Diameters | Ø600 · Ø800 · Ø1000 · Ø1200 · Ø1300 · Ø1400 · Ø1600 · Ø2000 · Ø2400 · Ø3000 mm |
| Height / length of design | From approximately 900 mm to 7100 mm, depending on volume, diameter and configuration |
| Installation method | Above-ground or buried design when provided for by the project and construction |
| Special designs | Thermally insulated tanks, double-wall tanks and tanks with equipment on request |
| Purpose | Drinking water, process water, firefighting water, wastewater, chemicals, fuel, food-grade liquids and process media |
| Equipment | Connections, flanges, valves, taps, level indicators, inspection openings, vents, overflows, step rungs, anchoring, nozzles and mixer supports |
| Color | Standard color or a color subject to agreement and production capabilities |
| Manufacturing | Made to order, according to volume, dimensions, type of medium and project technical requirements |
Plastiša guide
Not sure whether a plastic tank is the right choice?
Plastiša briefly explains when HDPE/PPH plastic tanks are a good solution, who they are intended for, when additional technical review is needed and what to prepare before sending an inquiry.
What are plastic tanks used for?
- For storing drinking water, technical water, fire-fighting water and irrigation water.
- For chemicals, technical liquids, process media and industrial use, subject to a material compatibility check.
- For fuel, oil, diesel, heating oil and similar media when such a configuration is envisaged by the project.
- For food liquids, fruit fermentation, alcoholic and non-alcoholic beverages, in accordance with the requirements of use.
- For wastewater, technical systems, production plants, farms and industrial facilities.
- For vertical storage when it is necessary to use space rationally and provide a larger capacity on a smaller footprint.
- For custom tanks with connections, openings, valves, vents, level indicators, insulation or a double wall.
Who are they intended for?
- Households, holiday homes and facilities that need a tank for water, technical water or auxiliary systems.
- Agricultural holdings, farms and systems for irrigation, water storage and technical liquids.
- Industrial plants, production systems and technical facilities that need to store process media.
- Chemical, food and processing industries, with a prior check of the intended use and storage conditions.
- Investors and contractors who need custom HDPE/PPH tanks for buildings, plants or infrastructure systems.
- Users to whom corrosion resistance, watertightness, low weight and simpler maintenance are important.
- Projects that need a tank with a volume from 250 to 50000 liters, according to the intended use, space and equipment.
When might a plastic tank not be the ideal choice?
- If an aggressive chemical, high temperature or specific industrial medium is stored, the compatibility of the HDPE/PPH material needs to be checked.
- If a pressurized tank is needed, a standard-configuration plastic tank is not a substitute for a dedicated pressure vessel.
- If the tank is buried or exposed to a large external load, it is necessary to check whether a special buried configuration or additional protection is needed.
- If the location has a high groundwater level, the anchoring, buoyancy protection and installation conditions need to be checked.
- If the tank is intended for drinking water, food liquids or a regulated industrial application, all necessary requirements and documentation need to be checked.
- If the user does not know the type of liquid, the temperature, the volume, the filling and emptying method, a consultation with the Plastopex team is recommended first.
- If structural calculations, fire-protection requirements, special certificates, permits or project documentation are needed, the final solution should be confirmed through expert review.
What to prepare before sending an inquiry?
- State the intended use of the tank: drinking water, technical water, irrigation, chemicals, fuel, food liquid, wastewater or another medium.
- Prepare the required volume, for example 250, 500, 1000, 2000, 5000, 10000, 20000 or 50000 liters.
- State whether you need a vertical, horizontal, above-ground, buried, insulated or double-wall tank.
- Prepare the approximate dimensions of the space in which the tank will stand, including height, width, access and base.
- State the filling and emptying method: manual, by pump, by gravity, via a pipeline, by truck or by process.
- State the required connections, openings, covers, valves, vents, overflows, drains, measuring elements or additional equipment.
- If a chemical, fuel or specific medium is stored, send the technical data sheet, temperature, concentration and storage conditions.
- Describe the site conditions: indoor or outdoor space, groundwater, sun, frost, traffic load and access for transport.
- Send site photos, a sketch, space measurements, an existing project or a technical drawing if available.
- State whether you need only the manufacture of the tank or also help with configuration, transport, assembly and connection.
Next step
Send basic details about the medium, the volume, the installation location, the filling method and the required connections. The Plastopex team will review the request and propose a suitable plastic tank configuration.
Plastiša's guide is informative and serves as help in choosing a product. The final volume, dimensions, material, wall thickness, connections, equipment, price, deadlines, transport, assembly and conditions of use are confirmed solely by the Plastopex team after reviewing the request.
